Model
BAR365-LT97
OS
Android 9.0
CPU
Amlogic T972,Quad-core ARM Cortex-A55 up to 2.0GHZ
GPU
Mali-G31 MP2, OpenGL ES 1.1/2.0/3.2,Vulkan 1.1,OpenCL 2.0
NPU
null
RAM
2G (4G optional)
ROM
16G (32G-64G optional)
Network
WLAN 2.4/5.8GHZ ,BT V4.2; Ethernet GLAN(1000Mbps)
Video Decoding
H.265 4K@60fps,1080p@60fps Mpeg1/2,Mpeg4,SP/ASP GMC,H.263,H.264,WMV9/VC-1 VP9,VP8,etc.
Photo Decoding
JPEG,BMP,PNG,GIF etc.
Special functions
Hardware watch time dog make system running stable
Screen rotation can change any display direction of four sides
Power management make device reasonable working schedule
Contents management system to publish any programs
Automatically cleared the redundancy by periodically
Provide API document for easy match with applications
Touch
null
Panel features
Size: 36.5 inch
Resolution: 1920x540
Display area: 878.112mm (H)x242.6mm(V)
White Luminance: 400nits
Contrast Ratio: 5000:1
Viewing angle: 89(R)/89(L)/89(U)/89(D) degree
LED Life: Min 40000 Hrs
Interface
USB2.0x1; OTGx1;DC power x1;TFx1;RJ45x1;
Speaker
null
Operating Temperature
0 to +60 degree
Power
DC 12V/5A
Accessory
Power adapterx1; Bracket(mounter)x1; User Manuelx1;(optional) RC x1;
Housing
Material: Metal; Color: white or black;
size: 908.4mmx269.4mmx47.5mm
Net weight
6.2kg
Package Size
1025mmx160mmx390mm
Installation
mount on shelf
