What is an Industrial Open Frame Display?
An industrial open frame display is a structurally designed product consisting of a display panel,
controller board, interface board, and power supply, offered in an open-frame design without an external casing.
These displays are primarily used in industrial environments where customized design and integration are required,
making them ideal for embedding into specific equipment or structures.
A sleeker, more powerful
Android OS all-in-one touch PC.
Experience fast and efficient performance powered by RK3568.
Specialized firm capable of firmware development and hardware customization.
Hardware auto On/Off with automatic RTC (Real Time Clock) system integration.
Support for 4K codecs.
Connectivity with HDMI and other ports.
Loaded with a variety of basic functionalities.
We welcome both additional development and bulk purchases of this product.
[Information] Small Size Display
SL101-M68T 10inch
DIMENTION : 241 X 158 X 23 (WxHxD)
CCD : 350CD
TYPE : Stand, Wall-mount
Rockchip RK3568 Quad-core Cortex-A55 up to 2.0GHz Processor
Equipped with a quad-core CPU for swift information processing!
A low-power, high-performance board achieved with a powerful and efficient processor alongside excellent power control features.
Create unique spaces with various Android solutions and circledisplay, featuring a distinctive aspect ratio.
Car Android System
Various Android contents that you can enjoy in the car!
The HDMI - OUT function enables various functions
such as sending advertisement images and bus guidance.
Make a unique menu for your store.
Don't put stickers every time you fix the menu!
Take advantage of digital signage that makes it easy to change menus and prices.
AIO system for consultation and signature
It boasts stability with a 10-point multi-touch panel for banks,
mobile phone dealerships, and hospital counseling systems.
Customers can earn points themselves.
With Android applications, customers can earn points on their own.
Customize it so that it can be useful in the store.
Provide APIs appropriate
for development environments
It provides various API configurations to suit various development environments.
Provides information to make the different environments available in Android OS compatible.
Useful built-in features
1. Free advertising programs (Shopvod LITE)
2. Log-catchable AUTOLOG CATCH
3. The screen rotation function allows rotation at the desired angle.
4. Provide development environment by granting SUPERROOT authority .
5. Screen scale functionality
Supporting firmware for development
Support firmware development according to the application and
equipment porting required by the client.
Specifications
MODEL | SL 101-MS68T |
Inch | 10” |
Brightness | 350 CD |
Power | 12V 3A DC |
Demension | W241 x H158 x D23mm |
Common List | |
CPU | Quad-core Cortex-A55 up to 2.0GHz |
GPU | Mali-T764 GPU, Supports OpenGLES 1.1 and 2.0 |
Memory (RAM / FLASH) | DDR3 RAM 2GB (4Gb Optional) / 16GB (32G Optoinal) |
Graphics | 4K H.264 and 10bits H.265 video decode, |
Resolution (OUTPUT) | 1080P multi video decode, 1280 x 720p, 최대 1920 x 1080p(Full HD) |
HDMI Version | HDMI 1.3 / 1.4 / 2.0 |
OS | Android OS 9~11 |
USB | 2.0 / 2port |
WIFI | WIFI 2.4Ghz / 5Ghz |
Bluetooth | Supporting Bluetooth 4.0 |
REMOTE | IR-type Remote controller |
Input / Output port | |
Input Port | USB 2.0 / 2port |
UART / Micro SD(TF) Memory Slot | |
LAN 10/100Mb Ethernet | |
High-Speed eMMC extension interface | |
Power input (DC) | |
Output Port | HDMI (Video and Sound) |
SPDIF for audio output | |
Wireless | Wifi (2.4Ghz / 5.8Ghz) |
IR Remote | |
Contents | |
Video Contents | Quad-Core Cortex-A17 up to 1.8GHz MKV, WMV, VC-1 SP, MP, AP, MPG, MPEG, DAT, AVI, MOV, ISO, MP4, RM, REAL VIDEO 8/9/10, Video Output 1080P, 3D decoding, BD / SBS / TAB / FP |
Video Codec | Mali-T764 GPU, Supports OpenGLES 1.1 and 2.0, 3.1 4K VP9 and 4K 10bits H265 / H264 video decoding, up to 60fps,1080P multi-format video decoding (WMV, MPEG-1/2/4, VP9, H.264, H.265), 1080P video coding, supports H.264/H.265 |
Audio Contents | WMA, FLAC, MP3, OGG, WAV |
Images Contetns | JPG, JPEG, MJPEG, PNG, GIF |
Language | ENG, CHI, KOR, GER (ETC Android os-provided language) |
