SPECIFICATION | ||||||||||||
 |  |
| ||||||||||
Specification | Screen Panel | LCD Panel (800 x 1280) | ||||||||||
| CD | 350CD | |||||||||||
| INCH | 10.1 Inch | |||||||||||
| Screen Out type | LVDS | |||||||||||
| Touch type | Capacitive touch screen | |||||||||||
| Speaker | 8Ω / 2W | |||||||||||
| Power | DC 12V 3A | |||||||||||
| Button | Power(on/off) | |||||||||||
| Demension | L225 x W245 x H375mm | |||||||||||
| Bezel size | Up, Down, left, right 15(mm) | |||||||||||
| Power consumption | 9~10W | |||||||||||
| Weight | 4KG | |||||||||||
| Main Board | Chipset | RK3288 Quad-Core | ||||||||||
| OS | Android OS 7.1 Nougat | |||||||||||
| CPU | Quad-core Cortex-A17 up to 1.8Ghz | |||||||||||
| GPU | Mail-T764 GPU, Supports OpenGL ES 1.1 and 2.0 | |||||||||||
| High performance dedicated 2D processor | ||||||||||||
| RAM | DDR3 RAM 2GB (4G optional) | |||||||||||
| Flash | EMMC 5.0 16G (32G optional) | |||||||||||
| Ethernet | 10/100/GIGA Ethernet LAN - RJ45 | |||||||||||
| Audio | 3.5mm Audio output | |||||||||||
| HDMI out | HDMI Up to 2.0 | |||||||||||
| HDMI 2.0 for 4K@60Hz | ||||||||||||
| TF Slot | Supprting UP to 256GB | |||||||||||
| OTG | Android Debug Port | |||||||||||
| Wi-Fi | 2.4Ghz / 5.8Ghz | |||||||||||
| BlueTooth | 4.0 | |||||||||||
| USB | USB type (Cameara, Keyboard, Mouse, ETC) | |||||||||||
| Supporting USB 2.0 Speed / 3port / FAT32, NTFS, exFAT | ||||||||||||
| Port | GPIO | GPIO A0, A1, A2, KEY, GND | ||||||||||
| SPK | Built-in port | |||||||||||
| MIC | Built-in port | |||||||||||
| LVDS | 3.3V, 5V, 12V | |||||||||||
| EDP | 3.3V, 5V, 12V | |||||||||||
| RS485 | Port : /dev/ttyS1 | |||||||||||
| RS232 | Port : /dev/ttyS3, /dev/ttyS4 | |||||||||||
| USB | 4Pin Type 3port | |||||||||||
| DC IN | 12V | |||||||||||
| POE | Supporting Power over ethernet | |||||||||||
| LED | RED, GREEN, BLUE | |||||||||||
| IR | IR Remote | |||||||||||
| Function | Resolution | Support RGB/Dual LVDS/Dual MIPI-DSI/eDP interface, up to 3840*2160 resolution | ||||||||||
| Multi-media | 4K H265/H264 video decoders | |||||||||||
| 1080P other video decoders (VC-1, MPEG-1/2/4, VP8) | ||||||||||||
| 1080P video encoder for H.264 and VP8 | ||||||||||||
| Video post processor: de-interlace, de-noise, enhancement for edge/detail/color | ||||||||||||
| Video Files | MKV, WMV, VC-1, SP, MP, AP, MPG, MPEG, DAT, AVI, MOV, ISO, MP4, RM | |||||||||||
| Video Codec | 4K VP9 and 4K 10bits H265 / H264 video decoding, up to 60fps, 1080P multi-format video decoding | |||||||||||
| (WMV, MPEG-1/2/4, VP9, H265, H264) 1080P video coding, supports H264/H265 | ||||||||||||
| Audio Files | WMA, FLAC, MP3, OGG, WAV | |||||||||||
| Image Files | JPG, JPEG, MJPEG, PNG, GIF | |||||||||||
| Video Bitrate | 20,000 Kbps or less | |||||||||||
| rooting | You can choice root, unroot. | |||||||||||
| RTC | Real Time Control (Power on/off and reboot) | |||||||||||
| Screen Rotation | 0, 90, 180, 270 Setup | |||||||||||
| Auto Catch log | Can save the auto catch log | |||||||||||
| advertising function | Built-in Shopvod lite | |||||||||||
| WOL | Wake on lan, Network service | |||||||||||
| ADB | Wire - OTG port, Wireless - same network | |||||||||||
| Flatform key | System root (prepare the flatform Key) | |||||||||||
| Language | Android os-provided language (english, chinese, korean, german, ETC) | |||||||||||
