Specifications
 |  | ||||||||||||
Product Specifications | Screen Panel | LCD Panel (3840*160) | |||||||||||
| CD | 500CD | ||||||||||||
| INCH | 47 Inch | ||||||||||||
| Screen Output Method | LVDS | ||||||||||||
| Built-in Speaker | 8Ω / 3W | ||||||||||||
| Power | 12V 3A Type C | ||||||||||||
| Dimensions | L1209(mm) * W62.9(mm) * H26(mm) | ||||||||||||
| Bezel Size | Top: 7mm, Bottom/Left/Right: 5mm | ||||||||||||
| Power Consumption | 20~22W | ||||||||||||
| VESA Size | 100 X 100 | ||||||||||||
| Weight | Product - 2.8KG | ||||||||||||
Board | Chipset | Amlogic T972 | |||||||||||
| OS | Android 9 | ||||||||||||
| CPU | Quad-Core ARM Cortex-A55 | ||||||||||||
| RAM | 2GB DDR3 | ||||||||||||
| Flash | 16GB EMMC | ||||||||||||
| Ethernet | 100MB/1GB(external-Optional) | ||||||||||||
| TF Memory | upports up to 256GB | ||||||||||||
| OTG | Android Debug Port | ||||||||||||
| Wi-Fi | 2.4Ghz / 5.8Ghz | ||||||||||||
| BlueTooth | 4.0 | ||||||||||||
| USB | Supports external devices such as cameras, keyboards, and mice with USB type | ||||||||||||
| 2.0 / 2 ports / Supports FAT32, NTFS, exFAT | |||||||||||||
| External terminals | USB | Micro USB 2.0 | |||||||||||
| Type C | DC POWER | ||||||||||||
| Micro 5pin | Android Debug Port | ||||||||||||
Function | Resolution | Support RGB/Dual LVDS/Dual MIPI-DSI/eDP interface, up to 3840*2160 resolution | |||||||||||
| Support Media Format | 8Kp24 10bit H.265/VP9 decoding | ||||||||||||
| 4kp60 AVS2 decoding | |||||||||||||
| 4kp30 H.264 decoding | |||||||||||||
| HDR10+, HDR10, HLG | |||||||||||||
| Video Files | MKV, WMV, MPEG, AVI, MOV, ISO, MP4, RM | ||||||||||||
| Video Codec | 4K VP9 and 4K 10bits H265 / H264 video decoding, up to 60fps, 1080P multi-format video decoding | ||||||||||||
| (WMV, MPEG-1/2/4, VP9, H265, H264) 1080P video coding, supports H264/H265 | |||||||||||||
| Audio Files | MP3, WAM, AAC, WAV, OGG, AC3, FLA | ||||||||||||
| Image Files | JPG, JPEG, MJPEG, PNG, GIF | ||||||||||||
| rooting | Option to select root or unroot firmware | ||||||||||||
| RTC | Real Time Control system allows for setting power on/off and reboot times for the device | ||||||||||||
| Automatic log catch | Function to store system logs | ||||||||||||
| ShopVodLite | Built-in advertising solution | ||||||||||||
| WOL | Wake on LAN, remote booting function using network | ||||||||||||
| ADB | Wired - OTG port, wireless - debugging of Android using network | ||||||||||||
| Platform key provision | Ability to use system permissions using platform key | ||||||||||||
| Supported languages | All languages supported by Android, such as Korean, English, German, etc | ||||||||||||
